Aviation Obstruction Light Controller, Stainless Steel 304 Body Material
This Controller is designed for outside use, it could monitoring all aviation obstruction lights connected with and output dry contact to CRM/IBMS control room. Best convenient for work performance
Advantages:
Input power: 220VAC, Output power: 220VAC (Others are available if request)
Enclosure is made of corrosion resistance and wind resistance stainless steel 304(SS316 is optional)
Surge protection, Lightning protection
Circuit-breaker
External photocell for day/night or day/twilight/nigh operation
There is a manual/auto switch inside, user could change light’s working mode when testing lights manually but not affected by photocell
Audio Alarm: when failure happens, it will speak loudly (Audio could be turned off if not needed)
Alarm output(Dry contact): NO COM NC
External photocell is available
The control capacity is customized depends on different project/request
Optional LCD screen: LCD screen is built-in side the controller, the working mode/status of all lights could be show on the screen
Optional 485 communication port: user could connect our controller with computer to control and monitor all lights connected
Built in an astronomical clock. Make the lights best protect your buildings.
More detailed parameter:
| Operating Voltage | 110VAC |
| Body Material | Stainless Steel 304 |
| Overall size(mm) | 480×300×172 (Standard, others optional) |
| Weight(kg) | 7.5 |
| Installation size(mm) | 440×260×θ10 (Standard, others optional) |
| Product Life Expectancy | Average 5 years |
| Humidity | 0%-95% |
| Wind Speed | 80m/s |
| Waterproof | IP65 |
| Options Available | Solar Power System |
Exclusive salesman:
Installation :
High quility:
After Sales Team:
We have Professional after-sales staff, you can contact us with any problems in your installation, configuration, commissioning, lighting work.We wholeheartedly help each customer.
